RV Single Deflection Grille

RV Single Deflection Grille

ASLI RV series is a set of grille made up of 1 set of individually adjustable horizontal air foil blades.

The grille will come in more sections for blade length that is more than 500mm.
Approximately 83% free area when blades are fully open.

Material

RV-A
Frame: Extruded Aluminium A6063
Blade: Extruded Aluminium A6063

RV-T
Frame: 1.0mm Galvanized steel
Blade: Galvanized steel

Surface Finish

Baked white powder coated as standard.
Others available upon request.

Measurements

All sizes are available upon request.

RV Single Deflection Grille.pdf
