RF Perforated Face Return Air Diffuser
RF Perforated Face Return Air Diffuser - Image 1
RF Perforated Face Return Air Diffuser - Image 2
RF Perforated Face Return Air Diffuser - Image 3

RF Perforated Face Return Air Diffuser

ASLI RF series is a type of grille with perforated face for free return air application. It is suitable for T-bar ceiling installation.

  • Suitable for the free return air application.
  • Most suitable for T-bar ceiling installation.
  • The model RF can just sit on the T-bar without any support.
  • Approximetely 43% free area.
Material

RF-A
Frame : Aluminium Extrusion A6063
Perforated Face : 0.7mm aluminium sheet

RF-T
Frame : 0.7mm galvanized steel
Perforated Face : 0.7mm galvanized steel

Surface Finish

Baked white powder coated as standard.
Other available upon request.

Measurements

(Standard Size Unit: mm)
300 x 600 (1’ x 2’)
600 x 600 (2’ x 2’)
Other available upon request.
