NASA 8Nm/16Nm 2 point & 3 point On-Off Control Fast-Running Rotary Damper Actuator
NASA 8Nm/16Nm 2 point & 3 point On-Off Control Fast-Running Rotary Damper Actuator - Image 1
NASA 8Nm/16Nm 2 point & 3 point On-Off Control Fast-Running Rotary Damper Actuator - Image 2
NASA 8Nm/16Nm 2 point & 3 point On-Off Control Fast-Running Rotary Damper Actuator - Image 3

NASA 8Nm/16Nm 2 point & 3 point On-Off Control Fast-Running Rotary Damper Actuator

ASLI NASA…08/16 16Nm Fast-Running Rotary Damper actuator Series are designed specifically for application into the HVAC market. ASLI high quality damper actuators have been designed for use with fast running air damper, butterfly valve.

  • 2 points and 3 points control
  • Shaft dimension Ø 10…20 mm /10…16 mm square
  • Universal Spindle Clamp for easy direct mounting
  • Anti-rotation bracket provided for stability
  • Manual over ride by push button when required
  • Adjustable angle of rotation between 0°…90°
  • Selectable direction of rotation
  • Parallel connection up to 5 actuators
  • 2 adjustable SPDT auxiliary switches when requested
  • Power saving at end stops
  • Actuators with 1 m cable on request
Material

Torque: 8 Nm | Running Time: 8 sec

Power Supply: AC/DC 24V

  • No auxiliary switch → Model: NASA 1-08
  • With 2 × SPDT switches → Model: NASA 1-08s

Power Supply: AC 230V ±10%

  • No auxiliary switch → Model: NASA 2-08
  • With 2 × SPDT switches → Model: NASA 2-08s

Torque: 16 Nm | Running Time: 16 sec

Power Supply: AC/DC 24V

  • No auxiliary switch → Model: NASA 1-16
  • With 2 × SPDT switches → Model: NASA 1-16s

Power Supply: AC 230V ±10%

  • No auxiliary switch → Model: NASA 2-16
  • With 2 × SPDT switches → Model: NASA 2-16s
