The VAV package consists of 2 parts, namely the thermostat and the EVC which is a combination of an actuator and a controller. The EVC’s are available in the stand-alone version (EVC) or in a BTL listed BACnet application specific version (EVCB).They are designed to control pressure independent single duct VAV or fan powered VAV with or without terminal reheat. The controller incorporates flow sensor, electronics and firmware of the VAV package. The EVC mounts directly to the damper jackshaft on the side of th VAV box. The attractive thermostat has a large LCD display with four push buttons for set point, occupancy override and programming.
Main supply 24 Vac
Integrated actuator and control module
Field configured VAV algorithms
True differential pressure sensor
BACnet® MS/TP communications (EVCB)
Auto Baud Rate
Micro-processor based backlit LCD thermostat
BACnet® service port on the thermostat (EVCB)
Simple air balancing and commissioning with the thermostat keypad
Copy Config function: Allows to push the configuration to other EVCs over the BACnet network.
Applications
The EVC is suitable for BACnet® or stand-alone pressure independent VAV applications and fully configurable.
Change-over, heating and/or cooling with 4 stages ON/OFF or TPM or 2 stages floating and 2 outputs 0-10 Vdc.
