NACA 2Nm / 5Nm 2-Point & 3-Point On-Off Control Actuator
NACA 2Nm / 5Nm 2-Point & 3-Point On-Off Control Actuator - Image 1
NACA 2Nm / 5Nm 2-Point & 3-Point On-Off Control Actuator - Image 2
NACA 2Nm / 5Nm 2-Point & 3-Point On-Off Control Actuator - Image 3

NACA 2Nm / 5Nm 2-Point & 3-Point On-Off Control Actuator

ASLI damper actuators are are especially designed and produced for applications in the HVAC systems with latest Switzerland technology. It has been developed to operate and position air dampers of different sizes.

  • Torque 2 Nm / 5 Nm
  • Damper neck size 0.3 m² / 0.75 m²
  • Power supply AC/DC 24 V and AC 230 V
  • Control 2 Point and 3 Point
  • 1 adjustable auxiliary switch (SPDT) when requested
  • Shaft dimensions: Ø 6 to 15 mm round / 5 to 10.5 mm square
  • Minimum shaft length 40 mm
  • Selectable direction of rotation
  • Adjustable angle of rotation
  • Actuator with 1m cable connection
Material

Torque: 2 Nm | Running Time: 60…90 sec

Power Supply: AC/DC 24V ±10%

  • No auxiliary switch → Model: NACA 1-02
  • With 1 × SPDT switch → Model: NACA 1-02 S1

Power Supply: AC 230V ±10%

  • No auxiliary switch → Model: NACA 1-02
  • With 1 × SPDT switch → Model: NACA 1-02 S1



Torque: 5 Nm | Running Time: 70…100 sec

Power Supply: AC/DC 24V ±10%

  • No auxiliary switch → Model: NACA 1-05
  • With 1 × SPDT switch → Model: NACA 1-05 S1

Power Supply: AC 230V ±10%

  • No auxiliary switch → Model: NACA 1-05
  • With 1 × SPDT switch → Model: NACA 1-05 S1
