ASLI Linear Floor grille with actuator is designed for use in raised floor air distribution systems, where the floor cavity is used as a pressurized supply air plenum and is suitable to apply as perimeter ventilation. FGPB-A creates vertical up stream flow pattern directed by extruded deflection bar at center core. Extruded aluminum bars creates aesthetically appealing and excellent durability.
FGPB-A
Materials Diffuser core : Aluminum A6063
Plenum Box : 0.7mm thickness galvanized steel
Insulation : 5mm P.E foam
Anodized or powder coated.
(Standard Size Unit: mm)
Face size : 500 x 200
