ASLI FLD Round Floor Diffusers are specially designed for use in raised floor air distribution systems, where the floor cavity is used as a pressurized supply air plenum. FLD produces a high velocity swirl air pattern with the guidance of guide vane in the basket. Maximum comfort level could be achieved by producing high induction rates of room air with the design of FLD. Aesthetically appealing FLD is accessable by removing the diffuser core to remove the dust in the dust tray.
Duct Size: Ø 100mm ~ 400mm
Velocity: 28m/s (5500fpm)
Temperature Rating: -30˚C ~ 150˚C
Pressure Rating:
250mm W.G. (+ve)
25mm W.G. (-ve)
Standard Length: 10m
Steel Wire: Ø 1.0mm ~ 1.2mm
Metalized Polyester Film: 0.012mm
Fiberglass:
25mm & 16kg/m³
25mm & 24kg/m³
25mm & 32kg/m³
50mm & 16kg/m³
50mm & 24kg/m³
50mm & 32kg/m³
